HORIZONTAL GLASS WASHING MACHINE EVOGLAS H-LINE

Horizontal Glass Washing Machine EVOGLAS H-LINE – Precision, Efficiency, and Industrial Quality

High-Performance Glass Washing Machine for Flat, Architectural, and Insulating Glass

The horizontal glass washing machine EVOGLAS H-LINE from the EVOMATEC EVOGLAS series is a fully automatic industrial system designed for the professional cleaning and drying of flat glass.
Developed specifically for insulating glass production, architectural and façade glass processing, and furniture and design glass manufacturing, it represents the highest standard of industrial engineering and performance.

With its robust steel frame construction, energy-efficient control system, and CE-certified components from SIEMENS, Lenze, Schneider Electric, and Pepperl + Fuchs, the EVOGLAS H-LINE ensures durability, reliability, and precise performance — engineered according to European industrial standards.

Advanced Technology for Precise Glass Cleaning

The EVOMATEC EVOGLAS series combines state-of-the-art control, water, and air systems in one machine designed for 24/7 continuous operation.
A smart washing and drying process, managed by a digital control system, guarantees consistent cleanliness, energy efficiency, and process stability.

Thanks to its modular design, the machine integrates seamlessly into existing glass production lines.
Whether for float glass, Low-E glass, laminated glass, safety glass, or coated glass, the EVOGLAS H-LINE delivers consistently high cleaning quality with minimal maintenance requirements.

Technical Specifications of the EVOGLAS Series

Performance Data

Working widths: 1300 – 2500 mm
Glass size: Min. 170 × 350 mm / Max. 2500 × 3000 mm
Glass thickness: 3 – 19 mm
Conveyor speed: 3 – 10 m/min (infinitely adjustable)
Power: 12 – 30 kW (depending on model)
Voltage: 380 V / 3 phases / 50 Hz
Machine weight: 1100 – 1850 kg

These parameters make the EVOGLAS H-LINE one of the most powerful horizontal glass washing machines on the European market.

Key Features and Equipment

Construction and System Design

Massive steel frame for vibration-free continuous operation
All water-contact components made of stainless steel (AISI 304) – corrosion-resistant and hygienic
Wear-resistant roller system for precise glass transport
Lenze frequency converters for smooth speed adjustment
High-pressure pumps and stainless-steel boilers for constant water quality
Dual water tanks with triple filtration system
Angled nozzle system for full surface coverage
Mechanical float with valve control for automatic water supply
Electronic water level sensor with motor dry-run protection
SIEMENS CE-certified electrical installation for industrial reliability
Removable stainless-steel trays for easy cleaning and maintenance
Optional spindle-lift system (55 cm stroke) for convenient servicing
Energy-optimized fan control – automatic kW adjustment based on glass size
Adjustable washing temperature for different glass types

Special Features

Pre-wash chamber with high-pressure nozzles (optional) for heavily contaminated glass
0.10 mm soft brushes – gentle cleaning of coated and Low-E glass surfaces
Digital glass thickness control (optional) via PLC system for precise adjustment
Sound-insulated blower unit for quiet, high-performance operation
Chain-driven conveyor for stable and uniform glass transport

Industrial Components and Electronics

EVOMATEC relies on proven premium manufacturers to ensure maximum process reliability and durability:

Lenze (Germany) – frequency inverters and motor drives
SIEMENS (Germany) – CE-certified automation and control systems
Schneider Electric (Germany) – power distribution and safety systems
Pepperl + Fuchs (Germany) – sensors for glass detection and process monitoring

All machines in the EVOGLAS series are CE-certified, low-maintenance, and designed for continuous 24/7 industrial operation.

Construction and Material Quality

Strength, Stability, and Serviceability

Welded steel frame for high structural rigidity
Stainless steel design – tanks, filters, screws, and piping completely rust-free
Vibration-free guidance systems for smooth operation even with thin glass
Service-friendly access to pumps, filters, and nozzles for quick maintenance
Modular layout – ideal for integration into automated production lines

Energy Efficiency and Safety

Smart Power Management and Industrial Safety

Automatic fan control adjusts output according to glass size
Thermally insulated tanks reduce heat loss and energy consumption
High-efficiency pump technology ensures consistent pressure at reduced energy demand
Motor protection and overload shutdown for maximum operational safety
CE-certified safety systems comply with international industrial standards

These systems guarantee lower operating costs, higher efficiency, and maximum production reliability.

Application Areas

The horizontal glass washing machine EVOGLAS H-LINE is suitable for a wide range of industrial glass processing applications:

Insulating and double-glazed glass production
Architectural and façade glass processing
Furniture and interior glass manufacturing
Window and door production (aluminum / PVC)
Laminated and safety glass fabrication

Its modular construction allows for flexible adaptation to all production environments — from small workshops to large-scale automated glass factories.

Advantages of the EVOGLAS H-LINE

Consistently high cleaning and drying quality
Reduced energy and water consumption
Low maintenance requirements
Quiet operation with full sound insulation
High production speed and precision
CE-certified safety compliant with EU standards
Long service life and industrial-grade durability

Conclusion – Efficiency Meets Precision

The horizontal glass washing machine EVOMATEC EVOGLAS H-LINE represents state-of-the-art glass technology for modern industry.
With its energy-efficient system, heavy-duty stainless-steel construction, and precision control technology, it offers a future-proof solution for industrial glass processing.

Whether for insulating glass, façade glass, safety glass, or furniture glass, the EVOGLAS H-LINE stands for cleanliness, reliability, and cost-efficiency in modern glass production.

EVOMATEC EVOGLAS – Quality and Precision Made by Evomatec.
Request your personal consultation now: Click here
